| Número de pieza | DLC0560AIG-3 |
| Marca | Other |
| Tamaño | 5.6 |
| Solicitud | IA |
| Resolución | 640×480 |
| Composición | LCM |
| Brillo | 800 |
| CR | 500:1 |
| Colores | 262K |
| Iluminar desde el fondo | WLED |
| Interfaz | TTL |
| marca de paneles | DLC |
| modelo de panel | DLC0560AIG-3 1 Compatible model |
| tipo de panel | a-Si TFT-LCD , LCM |
| Tamaño del panel | 5.6 inch |
| resolución | 640(RGB)×480 , VGA |
| modo de visualización | TN, Normally White, Transmissive |
| área activa | 112.896×84.672 mm |
| describir | 126.5×100×6 mm |
| superficie | Antiglare |
| brillo | 800 cd/m² (Typ.) |
| relación de contraste | 500:1 (Typ.) |
| mostrar colores | 262K (6-bit) |
| tiempo de respuesta | 10/15 (Typ.)(Tr/Td) |
| ángulo de visión | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| frecuencia | 60Hz |
| tipo de lámpara | WLEDEmbedded (LED Driver) |
| interfaz de señal | Parallel RGB (1 ch, 6-bit), 40 pins |
| voltaje de entrada | 3.3V (Typ.) |
| solicitud | IA |
| AT056TN03 | Innolux | 5.6 | 320×234 |
| AT056TN52 V.3 | Innolux | 5.6 | 640×480 |
| AT056TN52 V.5 | Innolux | 5.6 | 640×480 |
| AT056TN53 V.1 | Innolux | 5.6 | 640×480 |
| DLC0560AIG-3 | Other | 5.6 | 640×480 |
| HV056WX1-100 | HYDIS | 5.6 | 1280×800 |
| LQ6BN01 | SHARP | 5.6 | 320×240 |
| LTD056ET2F | TOSHIBA | 5.6 | 1024×600 |
| LTD056EV7F00 | TOSHIBA | 5.6 | 1280×800 |
| TM056KDH01 | Tianma | 5.6 | 320×234 |
| AA050ME01 | Mitsubishi | 5.0 | 800×480 |
| G084SN05 V8 | AUO | 8.4 | 800×600 |
| G101EVN01.0 | AUO | 10.1 | 1280×800 |
| G150XTN02.0 | AUO | 15.0 | 1024×768 |
| G190ETN01.1 | AUO | 19.0 | 1280×1024 |
| LM050QC1T01 | SHARP | 5.0 | 320×240 |
| LM32K10 | SHARP | 4.7 | 320×240 |
| LTA084C274F | TOSHIBA | 8.4 | 800×600 |
| PD080SL3 | E Ink | 8.0 | 800×600 |
| TX16D11VM2CCA | KOE | 6.2 | 640×240 |
