| Número de pieza | CLAA100XA22XV |
| Marca | CPT |
| Tamaño | 10.0 |
| Solicitud | PAD |
| Resolución | 1024×768 |
| Composición | LCM |
| Brillo | |
| CR | 800:1 |
| Colores | 262K/16.2M |
| Iluminar desde el fondo | WLED |
| Interfaz | LVDS |
| marca de paneles | CPT |
| modelo de panel | CLAA100XA22XV |
| tipo de panel | a-Si TFT-LCD , LCM |
| Tamaño del panel | 10.0 inch |
| resolución | 1024(RGB)×768 , XGA |
| modo de visualización | HFFS, Normally Black, Transmissive |
| área activa | 202.752×152.064 mm |
| superficie | |
| brillo | |
| relación de contraste | 800:1 (Typ.) |
| mostrar colores | 262K/16.2M (6-bit / 6-bit + FRC), CIE193150% |
| tiempo de respuesta | 25 (Typ.)(Tr+Td) |
| ángulo de visión | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frecuencia | 60Hz |
| tipo de lámpara | WLEDWithout Driver |
| interfaz de señal | LVDS (1 ch, 6/8-bit), 40 pins |
| voltaje de entrada | 3.3/13/18/-6V (Typ.)(VDD/AVDD/VGH/VGL) |
| solicitud | PAD |
