| Número de pieza | C065VL01 V0 |
| Marca | AUO |
| Tamaño | 6.5 |
| Solicitud | CNS |
| Resolución | 800×480 |
| Composición | LCM |
| Brillo | 550 |
| CR | 300:1 |
| Colores | 262K |
| Iluminar desde el fondo | WLED |
| Interfaz | TTL |
| marca de paneles | AUO |
| modelo de panel | C065VL01 V0 |
| tipo de panel | LTPS TFT-LCD , LCM |
| Tamaño del panel | 6.5 inch |
| resolución | 800(RGB)×480 , WVGA |
| modo de visualización | TN, Normally White, Transmissive |
| área activa | 143.4×79.2 mm |
| describir | 157.2×89.2 mm |
| superficie | Antiglare (Haze 25%) |
| brillo | 550 cd/m² (Typ.) |
| relación de contraste | 300:1 (Typ.) |
| mostrar colores | 262K (6-bit) |
| tiempo de respuesta | 10/15 (Typ.)(Tr/Td) |
| ángulo de visión | 55/55/40/60 (Typ.)(CR≥10)(L/R/U/D) |
| tipo de lámpara | WLEDWithout Driver |
| interfaz de señal | Parallel RGB (1 ch, 6-bit), 80 pins |
| voltaje de entrada | 3.3/10.5/13.5/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| rohs: | |
| solicitud | CNS |
