| Número de pieza | B140QAN01.1 |
| Marca | AUO |
| Tamaño | 14.0 |
| Solicitud | NBPC |
| Resolución | 2560×1440 |
| Composición | LCM |
| Brillo | 340 |
| CR | 700:1 |
| Colores | 16.7M |
| Iluminar desde el fondo | WLED |
| Interfaz | eDP |
| marca de paneles | AUO |
| modelo de panel | B140QAN01.1 |
| tipo de panel | a-Si TFT-LCD , LCM |
| Tamaño del panel | 14.0 inch |
| resolución | 2560(RGB)×1440 , Quad-HD |
| modo de visualización | AHVA, Normally Black, Transmissive |
| área activa | 309.35×174.01 mm |
| describir | 320.4×205.1×2.6 mm |
| estilo de forma | Slim (PCBA Flat, Depth ≤3.2mm) |
| superficie | Antiglare, Hard coating (3H) |
| brillo | 340 cd/m² (Typ.) |
| relación de contraste | 700:1 (Typ.) |
| mostrar colores | 16.7M (8-bit), CIE193172% |
| tiempo de respuesta | 30 (Typ.)(Tr+Td) |
| ángulo de visión | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frecuencia | 60Hz |
| tipo de lámpara | WLEDEmbedded (LED Driver) |
| interfaz de señal | eDP (4 Lanes), 40 pins |
| voltaje de entrada | 3.3V (Typ.) |
| solicitud | NBPC |
