| Número de pieza | AMS369FG03-002 |
| Marca | Samsung |
| Tamaño | 3.7 |
| Solicitud | MPH |
| Resolución | 480×800 |
| Composición | OLED |
| Brillo | 250 |
| CR | 10000:1 |
| Colores | 262K |
| Iluminar desde el fondo | self |
| Interfaz | TTL |
| marca de paneles | SAMSUNG |
| modelo de panel | AMS369FG03-002 |
| tipo de panel | AM-OLED , OLED |
| Tamaño del panel | 3.7 inch |
| resolución | 480RG(BG)×800 , WVGA |
| área activa | 48.24×80.4 mm |
| describir | 53.94×90 mm |
| superficie | Hard coating (2H) |
| brillo | 250 cd/m² (Typ.) |
| relación de contraste | 10000 : 1 (Typ.) |
| mostrar colores | 262K (6-bit), CIE1931106% |
| ángulo de visión | 80/80/80/80 (Min.)(CR≥200)(L/R/U/D) |
| interfaz de señal | Parallel RGB (1 ch, 6-bit) + SPI, 40 pins |
| voltaje de entrada | 2.6/2.8/2.8V (Typ.)(IOVCC/VCC/VCI) |
| solicitud | MPH |
