| Número de pieza | AM-800480AZTMQW-05H |
| Marca | AMPIRE |
| Tamaño | 5.0 |
| Solicitud | Industrial |
| Resolución | 800×480 |
| Composición | a-Si TFT-LCD, LCM |
| Brillo | |
| CR | 600:1 |
| Colores | 262K |
| Iluminar desde el fondo | WLED |
| Interfaz | |
| marca | AMPIRE |
| modelo | AM-800480AZTMQW-05H |
| tamaño diagonal | 5.0 inch |
| tipo | a-Si TFT-LCD, LCM |
| formato de píxel | 800(RGB)×480 [WVGA] 188PPI |
| configuración | RGB Vertical Stripe |
| área activa | 108(H)×64.8(V) mm |
| contorno tenue | 118.5(H)×77.1(V) ×7.41(D) mm |
| área del bisel | 110.6(H)×67.4(V) mm |
| tratamiento | - |
| luminancia | 500 cd/m² (Typ.) |
| relación de contraste | 600:1 (Typ.) (TM) |
| ver dirección | - |
| tiempo de respuesta | 2/6 (Typ.)(Tr/Td) |
| ángulo de visión | 75/75/70/60 (Typ.)(CR≥10) |
| modo operativo | TN, Normally White, Transmissive |
| color de soporte | 262K 47% NTSC |
| fuente de luz | WLED [3S7P] , 30K hours , With LED Driver |
| peso | - |
| diseñado para | Industrial |
| cuadros por segundo | 60Hz |
| panel táctil | Without |
| Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
